Modification and Sputtering of Inhomogeneous Multilayer Oxidized Metal Films by Low-Current Argon Ion Beams

封面

如何引用文章

全文:

开放存取 开放存取
受限制的访问 ##reader.subscriptionAccessGranted##
受限制的访问 订阅存取

详细

Results of generation of various suboxide layers on various thin oxidized niobium films by modification and sputtering of their surfaces with low-current argon ion beams are reported. Niobium films of various thicknesses were grown by magnetron sputtering on oxidized silicon substrates. Few stages of delicate ion bombardment were performed. The surface of films was studied by means of non-destructive methods of X-ray photoelectron spectroscopy and angle-resolved X-ray photoelectron spectroscopy. Chemical and phase film profiling was performed. It was found that during air exposure of niobium films of various thicknesses, layers of pentoxide and various stoichiometric and non-stoichiometric oxides had been generated. During ion bombardment, composition and thicknesses of the films did not change. Numerical modelling results showed that by delicate ion bombardment atoms of oxygen were mostly sputtered. It was the surface pentoxide niobium layer that was sputtered and modified. It was found that different layers of stoichiometric suboxides and pentoxides of other phases different from the initial phases had been formed. The composition of surface suboxide layers changed slightly. The results of this research show opportunity of generation of suboxide layers of various composition and thicknesses by changing parameters of ion irradiation of metal film surface.

全文:

受限制的访问

作者简介

D. Lukiantsev

Moscow Power Engineering Institute

编辑信件的主要联系方式.
Email: LukyantsevDS@mpei.ru
俄罗斯联邦, Moscow

A. Lubenchenko

Moscow Power Engineering Institute

Email: LukyantsevDS@mpei.ru
俄罗斯联邦, Moscow

D. Ivanov

Moscow Power Engineering Institute

Email: LukyantsevDS@mpei.ru
俄罗斯联邦, Moscow

A. Pavolotsky

Chalmers University of Technology

Email: LukyantsevDS@mpei.ru
瑞典, Gothenburg

O. Lubenchenko

Moscow Power Engineering Institute

Email: LukyantsevDS@mpei.ru
俄罗斯联邦, Moscow

I. Ivanova

Moscow Power Engineering Institute

Email: LukyantsevDS@mpei.ru
俄罗斯联邦, Moscow

O. Pavlov

Moscow Power Engineering Institute

Email: LukyantsevDS@mpei.ru
俄罗斯联邦, Moscow

参考

  1. Белов А.Н., Перевалов А.А., Шевяков В.И. // Изв. вузов. Электроника. 2017. Т. 22. № 4. С. 305. https://www.doi.org/10.24151/1561-5405-2017-22-4-305-321
  2. Gul M., Efeoglu H. // J. Mater. Sci.: Mater. Electronics. 2022. V. 33. № 10. P. 7423. https://www.doi.org/10.1007/s10854-022-07864-z
  3. Slesazeck S., Mähne H., Wylezich H., Wachowiak A., Radhakrishnan J., Ascoli A., Tetzlaff R., Mikolajick T. // RSC Advs. 2015. V. 5. № 124. P. 102318. https://www.doi.org/10.1039/c5ra19300a
  4. Nico C., Soares M.R.N., Rodrigues J., Matos M., Monteiro R., Graça M.P.F., Valente M.A., Costa F.M., Monteiro T. // J. Phys. Chem. C. 2011. V. 115. № 11. P. 4879. https://www.doi.org/10.1021/jp110672u
  5. Barman A., Saini C.P., Sarkar P., Satpati B., Bhattacharyya S.R., Kabiraj D., Kanjilal D., Dhar S., Kanjilal A. // J. Appl. Phys. 2015. V. 118. № 22. https://www.doi.org/10.1063/1.4936961
  6. Song W.D., Ying J.F., He W., Zhuo V.Y.-Q., Ji R., Xie H.Q., Ng S.K., Ng Serene L.G., Jiang Y. // Appl. Phys. Lett. 2015. V. 106. № 3. https://www.doi.org/ 10.1063/1.4906395
  7. Kasatikov S., Filatova E., Sakhonenkov S., Kona- shuk A., Makarova A. // J. Phys. Chem. C. 2019. V. 123. № 11. P. 6849. https://www.doi.org/10.1021/acs.jpcc.8b12053
  8. Lukiantsev D.S., Lubenchenko A.V., Ivanov D.A., Lubenchenko O.I., Pavolotsky A.B., Iachuk V.A., Pavlov O.N. The Formation of nanosuboxide layers in the oxide of niobium in low-power ion beam of argon // Proc. 3rd International Youth Conference on Radio Electronics, Electrical and Power Engineering (REEPE). IEEE, 2021. P. 1. https://www.doi.org/10.1109/REEPE51337.2021.9388002
  9. Лубенченко А.В., Иванов Д.А., Лубенченко О.И., Паволоцкий А.Б., Лукьянцев Д.С., Ячук В.А., Павлов О.Н. // Журнал технической физики. 2022. Т. 92. Вып. 8. С. 1172. https://www.doi.org/10.21883/JTF.2022.08.52779.68-22
  10. Lubenchenko A.V., Ivanov D.A., Lukiantsev D.S., Smirnov M.B., Pavlov O.N. Investigation of the effect of multiple oxidation and ion sputtering on the formation of inhomogeneous oxide layers on the surface of an ultrathin metal film // Proc. 5th International Youth Conference on Radio Electronics, Electrical and Power Engineering (REEPE). IEEE, 2023. V. 5. P. 1. https://www.doi.org/10.1109 REEPE57272.2023.10086730
  11. Fadley C.S., Baird R.J., Siekhaus W., Novakov T., Bergström S.Å.L. // J. Electron Spectroscopy Related Phenomena. 1974. V. 4. № 2. P. 93. https://www.doi.org/10.1016/0368-2048(74)90001-2
  12. Macak K. // Surf. Interface Analysis. 2011. V. 43. № 13. P. 1581. https://www.doi.org/10.1002/sia.3753
  13. Lubenchenko A.V., Batrakov A.A., Pavolotsky A.B., Lubenchenko O.I., Ivanov D.A. // Appl. Surf. Sci. 2018. V. 427. P. 711. https://www.doi.org/10.1016/j.apsusc.2017.07.256
  14. Lubenchenko A.V., Batrakov A.A., Shurkaeva I.V., Pavolotsky A.B., Krause S., Ivanov D.A., Lubenchen-ko O.I. // J. Surf. Invest. X-ray, Synchrotron Neutron Tech. 2018. V. 12. P. 692. https://www.doi.org/10.1134/S1027451018040134
  15. Doniach S., Sunjic M. // J. Phys. C: Solid State Phys. 1970. V. 3. № 2. P. 285. https://www.doi.org/10.1088/0022-3719/3/2/010
  16. Crist B.V. Handbook of monochromatic XPS spectra: The elements of native oxides. John Wiley & Sons, 2000. 519 p.
  17. Yeh J.J., Lindau I. // Atomic Data and Nuclear Data Tables. 1985. V. 32. № 1. https://www.doi.org/10.1016/0092-640X(85)90016-6
  18. Moulder J.F., Stickle W.F., Sobol P.E., Bomben K.D. Handbook of X-Ray Photoelectron Spectroscopy. A Reference Book of Standard Spectra for Identification and Interpretation of XPS Data. / Ed. Chastain J., King R.C. Physical Electronics, Eden Prairie, MN, 1995.
  19. Lubenchenko A.V., Batrakov A.A., Pavolotsky A.B., Krause S., Shurkaeva I.V., Lubenchenko O.I., Iva- nov D.A. An XPS method for layer profiling of NbN thin films // EPJ Web of Conferences. EDP Sciences, 2017. V. 132. P. 03053. https://www.doi.org/10.1051/epjconf/201713203053
  20. Biersack J.P., Haggmark L.G. // Nucl. Instrum. Methods. 1980. V. 174. № 1–2. P. 257. https://www.doi.org/10.1016/0029-554X(80)90440-1

补充文件

附件文件
动作
1. JATS XML
下载
2. Fig. 1. Detailed spectrum of the Nb line of a 100 nm 3d film after the second stage of exposure at a 0° sensing angle. The experimental data are indicated by circles, the theoretical interpretation of the spectrum is represented by a solid line, and partial theoretical spectra are shaded in areas

下载 (206KB)
索引源数据
3. Fig. 2. Detailed spectrum of the Nb line of a 100 nm 3d film after the first stage of exposure at a sensing angle of 40°. The experimental data are indicated by circles, the theoretical interpretation of the spectrum is represented by a solid line, and partial theoretical spectra are shaded in areas

下载 (117KB)
索引源数据
4. Fig. 3. Overview spectra of a 10 nm thick film before (1) and after three stages of ion exposure lasting 10 (2), 20 (3) and 30 minutes (4) and the results of chemical qualitative and quantitative analysis (the content of elements is indicated in %)

下载 (137KB)
索引源数据
5. Fig. 4. Decomposition of the Nb 3d spectral line after ionic modification (a). The results of decomposition of the Nb 3d spectral line of a 10 nm film before (1) and after ionic exposure lasting 10 minutes (2), 20 minutes (3) and 30 minutes (4) (b). The experimental data are indicated by circles, solid line – theoretical interpretation of the spectrum, partial theoretical spectra with shaded areas

下载 (428KB)
索引源数据
6. Fig. 5. Detailed spectra of the Nb 3d line of an oxidized niobium film with a thickness of 100 nm: 1 – before ion exposure; 2 – after the first stage; 3 – after the second stage

下载 (164KB)
索引源数据
7. Fig. 6. Detailed spectrum of the Nb 3d line before ion exposure. The experimental data are indicated by circles, the theoretical interpretation of the spectrum is represented by a solid line, and partial theoretical spectra are shaded in areas

下载 (152KB)
索引源数据
